Name: MOTHERBOARD MSI B560M PRO-E
SKU: 12024
Price: 10950.00 INR
Availability: InStock

Supports 10th Gen Intel® Core™ , 11th Gen Intel® Core™ , Pentium® Gold and Celeron® processors for LGA 1200 socket
Supports DDR4 Memory, up to 4800(OC) MHz
Core Boost: With premium layout and digital power design to support more cores and provide better performance.
DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
Lightning Fast Experience : PCIe 4.0
Turbo M.2 : Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
Audio Boost: Reward your ears with studio grade sound quality
Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.

Specifications

Model Name : B560M PRO-E
CPU Support: Supports 10th Gen Intel®Core™ Processors, 11th Gen Intel®Core™ Processors, Pentium®Gold andCeleron®Processors
CPU Socket : LGA 1200
Chipset Intel®: B560 Chipset
GraphicsInterface: 1x PCIe 4.0 x16 slot
Display Interface Support: 4K@60Hz as specified in HDMI™ 2.0b, VGA– Requires Processor Graphics
Memory Support : 2 DIMMs, Dual Channel DDR4-4800MHz(OC)
Expansion Slots: 1x PCIe 3.0 x1 slot
Storage : 1x M.2 Gen3 x4 slot 4x SATA 6Gb/s ports
USB ports: 4x USB 3.2 Gen 1 5Gbps(4 Type-A)6x USB 2.0
LAN Intel®: I219-V 1G LAN
Audio 8-Channel(7.1) : HD Audio with Audio Boost
